BigHorn™ Wheelchair Ramps

Description


Upgrade your space with BigHorn™ Wheelchair Ramps – the perfect blend of safety, durability, and style. Made from advanced recycled composite technology, these ramps provide a lightweight, slip-resistant solution for threshold transitions. The innovative StoneCap™ Coating uses ceramic-coated quartz crystals to ensure a UV-stable, long-lasting surface.

BigHorn™ Wheelchair Ramps Ramps seamlessly modify thresholds up to 1 1/4”, offering superior traction and a refined appearance. Unlike metal or aluminum ramps, they remain safe to use in wet or cold environments without becoming slippery. Each ramp features molded mitered ends for a polished finish and includes peel-and-stick adhesive tape for quick installation. Available in a variety of elegant colors to match any home decor.

The only recycled plastic transition ramps offering superior slip resistance with a ceramic quartz surface, making them the ideal choice for safe and stylish mobility solutions.

Note: Peel and stick adhesive comes free with every BigHorn Ramp.

Product Features

  • Includes molded flares and traction pads for safety
  • First patented 100% recycled lightweight plastic threshold ramp
  • Safest surface in threshold design, much safer than aluminum
  • Peel-and-stick tape for immediate installation
  • Perfect for wheelchairs, scooters and electric chairs
  • Can be vertically cut for height adjustment and notched to accommodate door jambs
Specifications
Performance Material Tests Load Capacity & Slip Resistance
Material Tests - ASTM D 2240 Hardness: 70 (Shore A) Load Capacity:
- Exceeds 4000 lbs per square inch when properly installed.
- ASTM C 1026-84 H20 Absorption: 0.05% Slip Resistance:
- Static Coefficient of Friction (SCOF): ASTM C 1028-96 (Dry: 0.10, Wet: 0.95)
- Meets or exceeds recognized standards for static friction, fixed-angle ramp walking, and surface roughness.
- SCOF values of 0.60+ are considered adequate for pedestrian traffic.


Installation Instructions

BigHorn™ Ramp Installation Guide

Congratulations on your new BigHorn™ Ramp! Designed for durability and easy access, these ramps are made from 100% recycled plastic and manufactured in the United States. Follow the steps below to ensure a smooth and secure installation.

Before You Begin

  1. Measure the Threshold Height:

    • Measure the height of your door threshold or patio landing to ensure the ramp fits properly.

    • If the height exceeds 1-1/2 inches, use the optional Shim-Johnny Kit to adjust the ramp height up to 2 inches.

  2. Prepare the Surface:

    • Ensure the installation surface is dry, clean, and free of dirt and debris.

  3. Tools Needed (if adjustments are required):

    • Standard power tools (for trimming or notching the ramp if necessary).

    • Safety gear (eye protection and gloves).

Warning: Always follow the manufacturer's safety guidelines when using power tools.

Ramp Installation Instructions

  1. Dry-Fit the Ramp:

    • Place the ramp against the threshold to ensure proper fit before removing the adhesive backing.

  2. Apply the Ramp:

    • Peel off the adhesive backing from the peel-and-stick tape on the bottom of the ramp.

    • Carefully position the ramp against the threshold, ensuring the thickest end is flush with the door.

  3. Secure the Ramp:

    • Press the ramp firmly onto the surface to create a strong bond.

    • For best results, place a heavy object on the ramp for 15-20 minutes to enhance adhesion.

Shim-Johnny Kit Installation (For Thresholds Over 1-1/2")

  1. Measure the Threshold:

    • Determine the height difference to know how much shim material is needed.

  2. Cut the Shim Strips:

    • Trim the thick end of the shim strips to the required thickness using scissors or a utility knife.

  3. Position the Shims:

    • Peel the backing from the Shim strips.

    • Space the strips evenly on the installation surface across the ramp's length.

  4. Attach the Ramp:

    • Remove the adhesive backing from the BigHorn™ Ramp.

    • Place the ramp on top of the shim strips, ensuring the thick end is flush with the door threshold.

  5. Secure the Bond:

    • Apply firm pressure to the ramp and shims.

    • Place a heavy object on top for 15-20 minutes to ensure proper adhesion.
